Description

10000L Drainable Chemical Tank

Water, Chemical, Molasses and Other Liquids

FEATURES

• 10,000 litre capacity.
• UV stabilised polyethylene tank with 25 year warranty.
• Specifically designed and suited to store a broad range of chemicals, molasses, water and liquids.
• Shallow tank feet for improved agitation and easy cleaning of trace elements.
• 100% fully drainable sump for ease of cleaning and decontamination of tank.
• Impact resistant tank with built in tuff flex technology.
• Suitable for a load rating up to 1.3 specific gravity (SG).
• Large 455mm tank opening filter basket.
• Easy to read tank calibrations on tank side.
• 3″ MBSP brass tank fitting.
• 6 mounting pins for easy and secure mounting.
• Complies with relevant sections of Australian Standards AS2070:1999 & AS4766:2006.
• Food Grade poly material that complies with Australian Standards AS4766:2006.
• Tank dimensions (mm) – 3600(L) x 2100(W)  x 1960(H).
• Tank with frame dimensions  (mm) – 3600(L) x 2100(W)  x 2114(H)
• Approximate weight 500kg.
• Pictured with optional steel mounting frame *
• Full manufacturers warranty.

ADDITIONAL OPTIONS

• Hot dipped galvanised steel mounting frame with pump plate and agitator mount provision.
• Ball baffles for load stability in transit.
• 2″, 3″ and 4″ brass tank outlets fitted to tank.
• Tank level kit

Specifically designed for a storing and transporting a broad range of chemicals, molasses, water and liquids across the agricultural, civil, industrial and mining industries.

Moulded from a specially blended polyethylene these sump tanks have an impressive 25 year warranty, are impact resistant and UV stabilised to deal with the harsh Australian sun.

The galvanised steel frame, with pump plate and agitator mount provision, makes it easy to mount the 10000L drainable chemical tank onto the back of most trucks.

The ‘V’ designed steel frames provides clearance and access to the sump for connection of hoses to fully drain the tank. Easy to read  calibration for measurement on the side of each tank and no spill containment lips allow chemicals to be added mixed.

The fully drainable sump tanks are manufactured in Australia and range in sizes from 100 litres to 13,000 litres.

DISCLAIMER:

Tank dimensions and weights may vary slightly due to manufacturing process. * Price quoted is for tank only. Steel mounting frame shown in images, and ‘Additional Options’ as noted above are not included in the tank price. For pricing and further information please contact our team.

10000L Drainable Chemical Tank.

TTi SumpTrans™.

Additional information
